Infrared panels

Infra Panel

Enjoy the heat of the IR panels and the versatility and efficiency of Infrared sauna. Our new efficient IR panels are covered by Hemlock wood and fabric, providing a soft touch to the skin. Choose between black or grey panels. Install as separate panels in an existing traditional sauna room or as a complete set in a separate infrared sauna room. Why limit your sauna enjoyment?

See all downloads >>

Installs in an existing traditional sauna room

Two sauna types in one room. Enjoy separately or simultaneously.

Infrared sauna goes deeper into your muscles and tissues.

Product specification
Size 980x360 mm / 980x680 mm
Black, item no. 90011295 / 90011298
Grey, item no.  90012303 / 90011304

37 mm

Cable 2 m heat resistant cable
Placement External on top of wall panel.
Effect 150 W or 300 W
Suitable control Elite control panel
Combined solutions
  • Infra panel + Elite control + Sense Elite heater
  • Infra panel + Elite control + Commercial Lite Relay + Sense Commercial/Expression heater (maximum 10,7 kW)
  • Infra panel + Elite control + Commercial Lite relay

The infra panels are controlled from the Elite control panel via relay box or heater.

The maximum load is 2,2 kW/2,3 kW for Sense Elite and Commercial Lite.

Example: If 4 panels with 300 W + 4 panels with 150 W are used the load will be 1,8 kW.
